Creality Ender 3 Pro TL Smoother Housing

Here a remix of the TL-smotther housing for Ender3 PRO to accomodate 4 modules. Unfortunately the orginal design was based on different tl-smoothers (different size).

NOTE: you need to trim down the pins of the tl-smooter (flush with the PCB surface)

TLSMOOTHER_HOSING.stl

TL-smooother details: SIZE: 29.8X40.5mm MODEL: BIGTREETECH Smoother V1.0

Notes Due the sizes of these modules, I thinned the side walls of tl-smoooter housing gaining the space needed to accomodate 2 fans as the original design.

Ender_Case_28x45.stl

TL-smooother details: SIZE: 28X45mm

Notes This model has not been tested, first, try to print the test model (TEST_HOLDER 48x25.stl) to verify that the module fits, than proceed with the full housing print.

Print Settings

Printer Brand:

Creality

Printer:

Ender 3

Rafts:

Doesn't Matter

Supports:

No

Infill:

40-80
