Logitech Mevo Fence Mount

I recently nerded out at my kids baseball games and started streaming games via my GoPro.

After a number of issues (like so many others) with the GoPro, I tried the Logitech Mevo, and had great success.  Problem was, I couldn't find a fence mount like there was for the GoPros.

So I got to work.

Another parent did up a new model of a new GoPro and shared to me and I liked how he did up the slider on the bottom to give it a bit of movement, so I incorporated that in as well, which makes it easy to get the Mevo installed and adjust a bit side to side.

A few small bungie straps from local dollar store or amazon and youre good to go.  I also added a strap to the top, but I havnt needed it yet, but its there if you need it. I also added a bit of a foam pad on the front where it touches the fence - but thats completely optional.

All you need is a ¼ - 20 Hex Machine Screw.  Length for me was .75inches or 20mm.  I found at local hardware store (I got mine at Canadian Tire).  In order to get the screw in, I had made a small recess for it as well.

I have run this in +30 heat, and the shade it adds sure helps.

The camera is recessed a bit back to help protect it from those pesky baseballs.

Print with organic supports worked for me.

I printed with .20mm layer height, .40 nozzle and 15% infill, but adjust as necessary.  Of course, if this is in the sun…you should print this in PETG.  But I wont stop you from doing PLA.

Hope you guys like it as much as I do!

Modified to work with the Logitech Mevo, but the base shell design was a great idea.
