Mini Modular Drawers 4cm

I searched for storage box on Thingiverse. I find O3D great design the Modular Drawers 2.0
but its too big for my small things (M2,M3 screws nuts, bullet connector etc.) Because of this i made the smaller version. The drawers knob originnaly designed by fipsthedog (i just use it :D).
Unfortunately the mini drawers not compatible with the big brother.

The dimensions:

• Single frame: 40x40x100mm
• Double frame: 80x40x100mm
• Single drawer: 33x33x97,5

• Double drawer: 73x33x97,5
  You find 2 different type for the single drawer. 1 with double aperture and 1 with quad aperture. The double version had only one version with 2 aperture.
  If you wanna make 1 aperture just cut out the middle wall on the 2 aperture drawer. This wall need to keep the side walls straight during the printing.
  The Frame don't need any adhesive to hold it together due the interlocking system.
  I printing it on my Anet A8 FDM printer.

  Printing material white & clear ABS
  I used a cheap ABS ~12€/kg and it works well
  You can buy it here:
  White
  Clear
  Blue
  Pink
  Green
  Grey
  Yellow
  Purple
  Orange
  Coffe
  Brown
  Black

Print instructions

Category: Tool Holders & Boxes Print Settings

Printer: Anet A8

Rafts: No

Supports: No

Resolution: 0,2mm

Infill: 20%

Notes:

Temp: 235°C nozzle, 90°C bed ( first layer 245°C nozzle, 100°C bed on glass coated with hairspray)
