Mitutoyo Dial Indicator Lugback Gridfinity Tray

Gridfinity tray for Mitutoyo 2046A (and similar) dial indicators with lug backs
0
2
0
15
updated June 20, 2025

Description

PDF

Gridfinity tray for Mitutoyo 2046A dial indicator, likely fits others with lug back, plastic cap on top, and dovetail features on the top corners. The indicator sits high enough you can grab onto the bezel, so I didn't include finger recesses. The lip is about one or two mm above the indicator to give a little protection.

Including version with and without a recess tray for accessories.
