Colorroom C5 Tablet Wall Mount

Fork, view, or even change configuration for the 3d Model using the OnShape CAD for this model.

This wall mount was made for the Colorroom C5 Tablet and a 90 degree usb-c cable.  I wanted to create a wall mount for the reasonably priced Android tablet that would let me easily remove the tablet and take it with me, since HA helpfully has controls for just about everything in my house.

I'm planning to add a more universal usb power system in the next iteration, along with a string of RGB leds for backlighting.


Assembly BOM:

9 - M3 x 5 x 4 Heat Set Insert
6 - M3 x 12 Socket Head Cap Screw
3 - M3 x 8 Socket Head Cap Screw

For mounting:

3 - # 8 drywall screws and 3 drywall anchors
