Prusa XL another nozzle cleaner for metal brushes

Hi,


This is my own idea of all the nozzle cleaner for brass brush nozzle cleaners.

So it is definitly inspired by all the others like
https://www.printables.com/model/643792-prusa-xl-nozzle-brush-scrubber-with-twist-lock-pru this but are design by myself.

You need some screws and inserts and the brushes.
Actually I wanted to do some silicon cleaners but ended up using brassbrushes to get it done.


Preparation:

for a 5T XL cleaner set you need

• 10x 3mm screw with ~ 8mm length
• 10x 3mm inserts
• at least 3 brassbrush

Cut the brushes in half and remove the rest :-)

print all the parts

• 1 mount-rail per tool head
• 1 brush-holder per tool head

Building instructions

• put the insert into the mount-rail
• put the brushes into the brush-holder
• screw it on the printer

Done!
