Pedestrian Traffic Light - Ampel (fuer Fussgaenger)

Description

Pedestrian Traffic Light

Quick and easy to build - Snap fit - no screws needed

Final dimension assembled: 4x4x15cm (LxWxH)

Print

• No support
• Orientation as in the files
• Infill 15%
• Material: PLA

Parts needed

• 1x WS2812 / Neopixel stick (or similar e.g.  https://www.roboter-bausatz.de/p/8bit-rgb-led-leiste-aehnl.-neopixel
• Jumper cable ≥ 20cm e.g. https://www.roboter-bausatz.de/p/40-pin-dupont-jumper-kabel-buchse-stecker-40-cm
• Microcontroller (Raspberry, ESP32, Arduino ,  Calliope,…)

Cut

Cut 2 pixel from the stick to make it fit into the housing. (see pictures)

Solder

Cut the jumper cable on one side and solder it to the LED stick (GND, 5V, DIN)

Assemble

• Insert the stick
• Fix the stick by using the spacer
• Push the cable including connector through the standpipe
• Connect the stand pipe

Connect & Code

Pls. note that the WS2812 (Neopixel) stick is directly connected to the controller. It does NOT need a own power source. Connect just the controller.

This is possible by using only a few LEDs. The controller can deliver enough current. Voltage 3.3V or 5V does not matter in this case.

Calliope:

LED Stick 5V → Calliope +

LED Stick GND → Calliope -

LED Stick DIN → Calliope P0

Code example:  to follow

ESP32:

LED Stick 5V → ESP32  3.3V

LED Stick GND → ESP32 GND

LED Stick DIN → ESP32 D16

Code example:  to follow

Arduino:

LED Stick 5V → Arduino 5V

LED Stick GND → Arduino GND

LED Stick DIN → Arduino D6

Code example:  to follow

You like it?

Leave a picture of your make and a “LIKE”

The traffic light visible in the background  you can find at:  https://www.printables.com/model/864750-traffic-lights-ampel-for-arduino-esp32-co

Problems?

Drop me a line by PM and I will try to help.

######################################################

More information about Neopixel, code examples, connections and warnings at: https://learn.adafruit.com/adafruit-neopixel-uberguide/the-magic-of-neopixels.
The sample code has been tested with original Adafruit Neopixel sticks and may require adaptation when using other sticks.

Disclaimer

Pls check the data sheet  of your microcontroller before connecting.

I do not take any liablity for damages or injuries. Build and use at your own risk. The linked products and pages are for reference only. I dont get paid  from the owners.

#######################################################
