[IKEA ÖVERSIDAN] magnetic LED Clip v2.0

I use this clips for IKEA ÖVERSIDAN LED (wardrobe lighting strp w sensor) inside a IKEA BROR cabinet. The 60x3.5mm variant for the lower part (below the shelf), the 50x23.5mm variant for the upper part (below the top side).

You need per clip:

• 2x countersunk head screw M3 x 10
• 2x insert M3 x 5 x 4.2
• 1x Rectangular Pot Magnet w. 2x Counterbores, 50/60 x 13.5 x 5 (N35 should be fine)

NOTE: Do not tighten the screws too tightly (the magnet may split).

Easy mounting of this bracket to LED by slide on from side.

Printed with PET-G filament from FIBERLOGY (EASY PET-G).

• added room for inserts
• added nibbles for better press fit of clip to the LED
