28mm Modified Plössl Eyepiece, 2" focuser

This is a 2" version of my 28mm eyepiece:

https://www.thingiverse.com/thing:4587751

This uses a lens set from Surplus Shed:

https://www.surplusshed.com/pages/item/L3820.html

This set consists of three lenses (eye, middle, field), and the following printed parts:

1. 2" housing with a 42.6mm dia. 1.5mm pitch internal thread,
2. Lens retainer with a matching external thread,
3. Three lens spacers, one each for the eye lens, middle lens, and field lens.
4. Flexible eye guard.

I made these from ABS except for the flexible eye guards. ABS is more durable, lighter, and has a less glossy finish than PLA. The eye guards are printed from black TPU

The vertical resolution of the print is important to get acceptable quality on the threads. I printed mine at 0.12mm vertical resolution and a speed of 20mm/s. You can print all the parts without supports, but some files may need to be flipped 180º when slicing.

I haven't yet used this eyepieces under the night sky. I have compared my previous design (https://www.thingiverse.com/thing:4580598) with a commercial 26mm Super Plössl from Meade. The 3D printed eyepiece compares very favorably to the commercial eyepiece. There's a little more distortion at the edges, and some chromatic aberration. A view of the moon shows color fringes, whereas the Meade eyepiece is color-free. Contrast is as good or better than the Meade lens, and I notice no internal reflections.
