USB-GC2

The USB-GC2 is a new USB-C mod for the Nintendo GameCube. It allows powering the console using a modern USB-C Charger, compatible with the Power Delivery protocol.

It's also compatible with both 15V or 12V charger, making it compatible with a variety of chargers, including the Nintendo Switch one! Input voltage modes can be selected using the onboard switch.

This second revision also contains a voltage spike protection, preventing damaging the console. This revision still keeps the original fan and power connectors, as long as the original power switch.

But most importantly, the USB-GC2 is now entirely open-sourced! Here is the GitHub repository. All the files are listed there, as long as assembly advice and requirements.

The cover shared here can be print in a layer thickness of 0.2 or thinnest, but the version with logo might need some more precise settings to get all the details of the logo.

You'll find the BitBuilt thread here: https://bitbuilt.net/forums/index.php?threads/usb-gc2-next-gen-gamecube-power-board.6925/

And the GitHub repository here: https://github.com/Xenii1642/USB-GC2/tree/main
