Battery Shell XL for the Dirtywave M8 M:01

Do you want to double (or quadruple) your M:01’s battery life?

Do you want to fix port crackle (more permanently) from flush ports (early M:01s)?

Do you want to mod out the color of your M:01 gameboy style?

Do you have a 3D printer?

If you answered yes to any of those questions, you’re now in luck!

Presenting 000cap's Battery XL Shell Swap for the Dirtywave M8 M:01

Brought to you by my trusty Mitutoyo calipers, many many hours spent 3D modeling, and test printing (and also Trash80 for making this amazing thing in the first place)!

Disclaimer

I checked with Trash80 if it was okay to share these designs. He said yes as long as it lacks any Dirtywave M8 branding, so if you mod these files please do not add any of Dirtywave or M8 branding. He also said that any repairs sent his way need to have the original aluminum shell back on the device. He will not be held responsible for any battery or switch issues that happened due to switching out parts.

Non-Printed Parts you'll need

Battery

• the flat 2500mAh (adafruit - if out of stock try the digikey link),
• the cylindrical 4400mAh (adafruit - if out of stock try the digikey link)

Fasteners

• m2.5 x 6mm https://www.mcmaster.com/91698A242/

Heat-set inserts (if you want to use them)

• m2.5 https://cnckitchen.store/products/gewindeeinsatz-threaded-insert-m2-5-standard-100-stk-pcs
• m3 https://cnckitchen.store/products/heat-set-insert-m3-x-3-short-version-100-pieces

If you're into this (and able to) send me some love https://ko-fi.com/000cap

Working towards the gift economy!

✌
