Mounting adapter for Fysetc Spider v2.2 and Pi Zero 2 W

Adapter to mount a Fysetc Spider v2.2 board in an Ender 5 electronics box, with a Pi Zero 2 W on side and cable routing
2
28
0
656
updated February 13, 2022

Description

PDF

This is an adapter that fits onto the standoffs on an E5 pixie enclosure box, and allow snap-in mounting of a Fysetc Spider board. It has cable guides:

  • e.g. endstops and such can be run on the left side below the guide
  • power in and bed and heater outputs have a guide in front and can be fixed by using a small (3 mm wide, 1 mm thick) cable tie
  • Stepper driver cables can be wired on the right side under the guide there
  • There are two additional slots on the right to run cables to and from the Pi Zero 2W (and potentially other auxiliaries)
