2x DC Jacks 1.4mm Inner, 3.4mm outer diameters (NES/J 135)
Hardware
4x M3x20mm bolt
6x M3x12mm bolt
4x M3x8mm bolt
8x M3 nut
4x M3 washer
4x M2x8mm bolt
4x M2 nut
4x standard computer fan screws (don't know the reference)
4x 22mm diameter circular rubber feet
Build Instructions
Printing
The grill prints face-down on the print bed, it needs internal support at each corner for the nut fittings.
The Housing print with the edge interfacing with the grill down on the print bed, it also needs support at each corner for the nut fittings used for the rack assembly. A brim can be useful to reduce wrapping on this part.
The rack prints with the back of the unit down on the print bed (where all the connectors will be), it requires support to the print bed at each corner for the bolt holes.
Use PET or other temperature resistant material (PLA is not suitable as sustain exposure to temperatures above 40°C will degrade the material).
Account for the material shrinkage ! In my case I printed X and Y dimensions at 100.4% for all 3 parts, using Prusa PETG.
Assembly
Press-fit 4 M3 nuts, one in each corner of the GRILL, it's a bit tricky because they got from inside, use a bolt to press them well into the fitting.
Press-fit 4 M3 nuts, on in each corner of the HOUSING
Assemble the FAN to the GRILL using the 4 fan screws, make sure the cable is at the right side of the GRILL when looking inside the unit (the bottom of the GRILL is indicated by the two circular emplacements for the rubber feet)
Assemble the HOUSING to the GRILL using 4 M3x12 bolts
Assemble the PSU to the RACK using 4 M3 washers and 4 M3x8 bolts
Press-fit 4 M2 nuts at the top of the RACK, from the inside at the RPI emplacement
Assemble the RPI to the RACK
Wire the electronics (see section below)
Place your Hard-disks into the RACK's slots
Slide the RACK into the HOUSING
Electrical wiring
Optional FAN driver circuit (can work with Vcc=5V or Vcc=12V):
