Märklin H0 modular Bridge Rail-C R1-30° Element (single part) / Märklin H0 modulare Brücke Gleis-C Element R1 30° (einteilig))

Motivation

When bulding a temporary model railway bridge or ramp, you need pillars with various sizes.
Using Lego for this purpose did not look too realistic.
For this reason I designed a pluggable model railway pillar system, that allows you to create any pillar height you need.
For a more realistic look of the bridge I designed a rail element for the curved Rail-C radius R1 30° rails.
The elemts fit on top of the modular Bridge pillar system and can be connected with snap-in-connectors.
The design leaves enough tolerance for the changing slopes needed for the bridge ramps.

The Märklin Rail-C system is intended to be used with for use with our design.


Print

Printed with prusament PLA (Gentleman's Grey)
To build a comlete ramp or bridge with ramps, you need quite a number of pillars and rail elements.
For one complete straight rail element you need to print the following components:
  1x H0_Bruecke_R1_30deg_v02.stl
  2x H0_Bruecke_Verbinder_v01.stl (one side)


Assembly

[Rail Support Element R130 v02 complete]
The curved R1 rail support element is printed as a single part.

The snap-in-connectors go into the small openings (left+right) at the ends of the rail support element.
The connected rail support elements fit on top of the pillar system.

Play & Enjoy!!!
