Chamber Air Filtration, 7530fan

Another variant of the chamber air filtration. Bento box was too bulky and Bento Mini uses not available to me 6028 fan. So I took inspiration from Mini and designed from the ground up a system that uses 7530 fan and has way less parts to print.

Not technically a remix, but HEAVILY INSPIRED

You will only need to print Bottom, Cover and attachment piece if you need it.

For attaching cover to the box you will need 6 M3 heat inserts of your choice (the holes are 4mm, so any insert will fit. I recommend using Voron design specification for the heat inserts) and 6 M3*8mm screws.

Assebmly is straightforward - print the Bottom and the cover, put activated carbon granules into the compartment, secure with M3 bolts. That's it.

Oh, I forgot, you'll need to open your 7530 fan, take off top part, and cut the bottom part so it will fit into the printed box.

Significant changes in size, construction and appearance.
