This model is designed to be done in a single print on a 255mm or larger printbed. The .step file is included if you would like to make any altercations to the model.

All of the walls of the mount are 6mm thick and the bottom of the mount is 8mm thick, all with 3mm fillets to help avoid any cracking on edges.
There is 1mm of clearance around the body of the Mac to prevent scratching when installing or deinstalling the Mac from the mount.
The circular cutout at the bottom for the Mac's standoff/bottom intake vents is near 0 clearance to prevent any movement in the mount.
The back of the model is almost entirely cutout due to all of the ports and exhaust vent.
There is a 4mmx6mm \u201crafter\u201d along the top of the back, this is probably not necessary and could probably be eliminated if you wanted but I wanted to leave in as much support as possible.

I printed using PETG at 100% infill, which was almost certainly overkill but I didn't ever want to risk warping or cracking. At 100% with support trees it was 718.5 grams and took 28.5 hours on my Bambu A1.

I would recommend using PETG, PETG is stronger, more temperature-resistant, and less brittle than PLA+ making it better for structural parts like a rack mount that may bear weight or face stress over time. However, PETG is quite stringy so be prepared to hit it with a light sanding once complete to break off those strung out pock marks.

In my application I was using reducer brackets to install it into a 19\" rack. So I have not personally tested the fit in a 10\"/11\" rack. However, in version 2 I made all of the screw holes on rack unit standards.
