HBVCAM enclosure and mount for Qidi X-Plus

This is an enclosure and mount for the HBVCAM v20234 v22 for Qidi X-Plus. It mounts directly under the front lip of the top cover where there is a pre-formed screw hole in the plastic housing, so no drilling is required (see pictures). This should fit other HBVCAM models that use the same form factor, including ones that are superior to this .3 Mega pixel, $2 potato-cam impulse buy off Ali. The mount could be modified fairly simply for other use cases and/or printers, STEP files are included if you wish to do so.

I printed in PETG, if you regularly print in ABS in your X-plus it's probably the lowest you should go temperature-resistance-wise.

Assembly is straight forward, place the cam with cable connected into the bottom half, snap top on, then insert the entire enclosure into the mount. There are no screws holding it together, the pivot points at the end of the camera enclosure should stay together when in the mount, holding both halves together good enough as there really is not any load on these parts. After assembling, place on the railing and use a M3 4 or 6mm screw to secure it. There should be enough clearance to not impede full forward travel of the carriage when printing.
