Neutral Labs Elmyra 2 Cover/Decksaver

A robust protective cover/decksaver for the Elmyra 2 synthesizer by Neutral Labs. I use it to place the synth in my backpack. A rubber band helps for the cover to stay on. Decksaver can be used to raise the synthesizer a little bit (see photos).

The model includes slots to store the preset cards that come with the synthesizer. It has enough clearance that the cover can be put on even with preset cards installed in the preset card slot.

My print settings: 2 perimeters, 4 bottom and 5 top layers, 15% cubic infill. Scarf seams. Single perimeter on all top surfaces. Only one perimeter on first layer. Used about 135g of filament.

Please note: I calibrated my printer to account for ~0.2% PETG shrinkage and designed this model accordingly, but clearances should be big enough for the print to fit even with profiles that aren't calibrated for shrinkage.

If the model turns out too tight or too loose on your printer, I included a parametric FreeCAD file where you can change most dimensions by editing the variables in the ‘cfg’ VarSet.
