Ford H11 headlight bulb holder

Replacement bulb holder for a H11 headlight/headlamp bulb holder in a 2015 Ford C-max. Modeled in Fusion (F3D Uploaded).
0
31
0
102
updated April 19, 2025

Description

PDF

I discovered this part was broken on a family member's car causing misalignment of the bulb. A few prototypes later this is what I ended up with.

Seen here printed in PETG. ABS/ASA would be a better choice but I was under a time crunch.

Printed with supports as the bottom is not flat. The bulb positional stops were a bit long in my case and were trimmed after printing with a pair of wire snips. The fit otherwise was very good and installed without other issues.
