3D printed RC skidsteer V4.0 upgrades

14/06/25

Re-modeled the merged wheels so the axle fits better. New one is called WheelMergeV2

Original:

A collection of files i made for the V4 mini skiddi includes

FatterArmClip - Mine needed to be bigger to prevent arm skew

ArmGear_levV4_scaledLarger - Needed to be bigger (from 21.5mm to 23mm) to engage pinion gear (for me). Scaled this in the slicer. This works with levs v4 pinion gear

ArmGear_Herringbone - Made an even larger gear from scratch to engage even better (for me). Made it a herringbone gear for kicks

PinionGear_Herringbone - to go with the new arm gear

Longer9Vtray - 9V battery works great, longer tray prevents it from coming out as much

Wheel_levV4_MoBetta_merged - this is a merge of the RC skidsteer track upgrade “MoBetta wheels” and levs v4 wheels… so you can use his driveshafts and the new wheels. Simply added them together in the slicer

PrettyGoodTensionerPulley - A better tensioner pulley I designed to work with the MoBetta wheels

PrettyGoodTrack - A new track I designed to work with the MoBetta wheels

Notes:

I printed and used the professor boots v3 cage as the LED cut outs are the right size for me. I also used the v3 rear door as it closes and opens easier
