BrewPi-ESP8266 Box - "All-in-One" v1.0

This is a version of the original case that I designed for the “main” PCB for the BrewPi-ESP project, adapted specifically for the “All-in-One” PCB.

As the years have gone on, I have designed multiple variations of the PCB – this case is for the latest PCB design, where the power supply and relays are combined on the same PCB as the controller.

There are multiple lids available for this design, depending on the screen type you plan to use:

• Lolin D32 Pro 2.4" TFT - Lolin's TFT designed for use with the D32 Pro, which utilizes a specific ribbon cable for connecting the TFT to the Controller
• Generic 2.8" TFT - A generic 2.8" ILI9341-based 320x240 pixel TFT, connected using one of several methods to the controller PCB
• Generic 3.2" TFT - A generic 3.2" ILI9341-baesd 320x240 pixel TFT, connected using one of several methods to the controller PCB

I am releasing both the OpenSCAD source as well as pre-rendered STL files – the STL files have had their corners filleted with a 1.5mm radius in Fusion 360.

If you would prefer not to print this yourself - or need a PCB to complete your build - I offer both the case and full kits available for sale on my Tindie store, in addition to making the source files for both the case and PCB available on GitHub.
