Adjustable Pushblock

Adjustable Push block for use with tablesaws and router tables
11
41
1
209
updated March 30, 2025

Description

PDF

8x M6 nut

Optional 2x 5mm m6 heat inserts.

8x M6 20mm

2x 20-30mm M6 Phillips/Allen Head

Rubber Coating/Tape

Print one of each model but two of each of the knobs and spacer may be required for the handled depending what

The Nuts are embedded, so make sure you add a pause in the think wall and main body models at the correct times. There is also a sacrificial layer to improve printing, so cut it out with anything sharp or force the bolt through it.

Can add a 5mm deep m6 heat insert to the thin wall, but I doubt it will be strong enough to put any major force on it.

Add rubber to the feet, I used some foam seal tape but flex seal or similar will work better

Use the microJIG GRR-RIPPER-style Handle from @NightMyst_179437

https://www.printables.com/model/591443-microjig-grr-ripper-style-handle

Model origin

The author marked this model as their own original creation.

License
