Dye Rotor Anti Jam Pull Tab

Replacement anti jam trigger/pull tab for a Dye Rotor.
0
1
0
6
updated March 30, 2025

Description

PDF

Remixed the original design to be closer to the OEM trigger from Dye in width and shape. I printed it upright on the nose with organic supports and no rafts @ .22mm layer height with Elegoo PLA+ (see attached for reference).





Model origin

The author remixed this model.

Dye Rotor Anti Jam Tab
by AutoFon82 (thingiverse.com)


Differences of the remix compared to the original

Remixed the original design to be closer to the OEM trigger from Dye in width and shape as well as the stem that engages the gears to be slightly taller, the original had lots of trouble consistently working with mine.
