15° ceiling mount for Samsung HW-K650 / HW-K651 soundbar

15° ceiling mount for Samsung HW-K650 / HW-K651 soundbar that attaches to the original mount points.
1
1
0
43
updated March 14, 2025

Description

PDF

15° ceiling mount for Samsung HW-K650 / HW-K651 soundbar (and possibly other Samsung soundbars with an 88mm deep casing) that attaches to the original mount points. Requires two M4x30 screws and ideally two 4x12mm washers for the mounts on the soundbar and takes whatever you have lying around for the ceiling mounts. Holes for that are 5mm and have space for 12mm washers as well.


I've printed it in ordinary PLA, 0.2mm layer height and 3 outer walls. Feels like that was overdoing it a bit, but, eh, it works.
