Rigid Bracket and Swivel Bracket for HSW

These brackets were designed originally to wall mount my Mayflash Arcade stick F500 V2, but with the versatility of the HSW, it can be used to hold or mount a range of bulky items.

The rigid bracket prints in 2 parts, 1 left and 1 right side, flat on the bed, with no supports. Glue the two sides together and if you wish you may use 5mm ‘system screws’ (10mm long, counter sunk) to hold it all in place.

The swivel bracket also (technically) prints in 2 parts, 1 left and 1 right side, however the swivel end will also be loose to allow the swivel motion. Print flat on the bed, with no supports. Glue the two sides together ensuring you don't glue the arm and the swivel together and only their corresponding L and R sides.

These have not been extensively weight tested however my setup is currently comfortably holding 2.5kgs.

OnShape source CAD here: https://cad.onshape.com/documents/4b54acae268e59a710419c72/w/d39d0d0209da46c7422305cc/e/8529f67a3a6e222831c3d5d6?renderMode=0&uiState=67d3d2f817cabc3016985f32

Rigid bracket and swivel bracket attached to empty insert, no additional wall fixings required.
