HSW holder for protractor / angle finder

Honeycomb storage wall holder for a protractor / angle finder ruler. Prints as a separate front and back panel which snap together.

The .stl files create a holder for a right-facing protractor as shown in the picture. Mirror these to create left-facing holder.

The default model fits a protractor with dimensions:

• protractor radius 52.5 mm
• ruler width 14 mm
• overall thickness (clearance) 3 mm

You can change these dimensions by editing the Spreadsheet in the attached .fcstd file using FreeCAD.
