LM393 light sensor case

Case to hold an LM393 light sensor. I am using the LM393 to measure the pulse indicator on an electricity meter. The sensor is plugged into a microcontroller running mysensors.org sending the data into my Home-Assistant instance

To get the sensor to fit nicely on the meter I removed the light sensor and re-soldered it flush to the board. The sensor mount can then be stuck to the meter with self adhesive hook and loop tape.

Printing:

Printed at 0.15mm layer height in PLA. No support is required.

The top clips in snuggly when you are ready to seal up the box.

Print Settings

Printer Brand:

Prusa

Printer:

i3 MK3

No

Supports:

No

150

Infill:

20
