LED light ring for dart cabinet

Lighting ring for apllication in a dartboard cabinet.
0
4
0
130
updated March 16, 2025

Description

PDF

Needed a fit-to-size light for my dartboard cabinet.

On fold-in  feet, with additional storage so the ring can be @ aproxx 16 cm above the board when in use, but stores low-profile when the doors are closed.

Printed in Polymaker PETG / 10 % fill / some supports needed

All parts fixed with CA glue , leg to foot connection screws 3x25 , foot to case screws 3x12

No wall-socket near so I used 5V LED strip and a solder-on USB-C socket so it runs on a powerbank.

https://www.amazon.nl/dp/B0CPLQQQF9?psc=1&ref=ppx_pop_dt_b_asin_title

https://www.amazon.nl/WOWLED-Niet-Waterdichte-Aangedreven-Stemming-Verlichting/dp/B08B87JDTL?pd_rd_w=PpTio&content-id=amzn1.sym.22774364-dba3-440b-9f2d-89140b5bc3ae&pf_rd_p=22774364-dba3-440b-9f2d-89140b5bc3ae&pf_rd_r=4SSDSSHWSS3FP31ZR7E7&pd_rd_wg=DRlgk&pd_rd_r=ac9f3ee0-38ec-43ea-9d46-be6afe2bf90c&pd_rd_i=B08B87JDTL&ref_=pd_bap_d_grid_rp_0_1_ec_pd_rhf_ee_s_rp_c_d_sccl_2_5_t&th=1
