Secure DIN Rail Mount for PSUs
This print mounts large power supplies with a 150x25mm bolt pattern on end on DIN Rails.
1
3
0
23
updated March 9, 2025
Description
PDFThis print mounts large power supplies with a 150x25mm bolt pattern on end on DIN Rails.
Bolt Pattern of PSU: 150mmx25mm
Material: tested with PLA
Bolt Holes: Intended for M4, but M3 might also work. I can upload a M3 version if there's interest.
Model origin
The author remixed this model.
Differences of the remix compared to the original
Adapted the mount to mount power supplies. Increased it's width, making it more stiff against rotation. Increased flexure stiffness by adding a rib.
