Toggle Clamp for CNC Workpiece holding

Additional Hardware:

4 x M3 Bolt, 30mm

4 x M3 Nut

1 x M6 Bolt (Hex head), 30mm

1 x M6 Nut

1 x M6 Bolt (round head), 20-30mm

IMPORTANT: The Hex head bolt needs to turn freely in the "Base" part, but needs to be fixed permanently to the “wheel”. This can be done with super glue. The M6 nut sits in the slot of the CNC and by turning the wheel, the clamp will be firmly fixed to the table.

Use plenty of lines when slicing (ca. 10) and 40 to 80% infill).
