Looploc (square) buckle kit (15-60mm)
Looploc (15-60mm) provides secure fastening and adjustable spacing for various applications.
2
10
0
39
updated March 31, 2025
Description
PDFLooploc (15-60mm) provides secure fastening and adjustable spacing for various applications.
| Type | Inside size | Outside size | Height |
| 15 mm | 8x16 mm | 15x23 mm | 2.5 mm |
| 20 mm | 8x21 mm | 16x29 mm | 3.0 mm |
| 25 mm | 8x26 mm | 16x34 mm | 3.0 mm |
| 30 mm | 8x31 mm | 16x39 mm | 3.0 mm |
| 35 mm | 10x36 mm | 18x44 mm | 3.0 mm |
| 40 mm | 10x41 mm | 18x49 mm | 3.0 mm |
| 45 mm | 12x46 mm | 21x55 mm | 3.0 mm |
| 50 mm | 12x51 mm | 22x61 mm | 3.0 mm |
| 55 mm | 14x56 mm | 25x66 mm | 3.0 mm |
| 60 mm | 14x61 mm | 26x72 mm | 3.0 mm |
Tags
Model origin
The author marked this model as their own original creation.
