Æthervox EMF Microphone Enclosure & Mic Clip

This is the enclosure and microphone clip for the Æthervox electromagnetic field microphone which can be found here: https://git.sr.ht/~slyka/aethervox

The main body of the enclosure should be printed laying down with the switch/graphics side facing the bed and only needs a small amount of support inside the XLR jack. If the print bows up at the ends during printing use a brim to make sure it stays stuck down. If you want the version with the graphics print the graphics first, then print the rest of the model on top using a different color.

The bushings and cushion for the mic clip should be printed from a soft TPU. I'm using colorFabb varioShore TPU.

For the final assembly you'll also need an XLR plug insert with matching M2.5x5 screw and an M5x25 bolt, an M5 nut and a 5/8" to 3/8" mic thread adapter for the mic clip.

Source files for the enclosure and clip can be found here: https://git.sr.ht/~slyka/aethervox-enclosure
