6-inch Rack Mount | Ubiquiti UXG Lite

A 6-inch rack mount for the Ubiquiti UXG Lite.

My intention is for the ports to face the “front”, but since the UXG Lite is square (98mm x 98mm) it can technically be set in the mount facing any way you want (though only front or back would work, as the support arms would block the ports in the sideways directions). The only downside is that the UXG's status lite is on the opposite face from the ports, so it isn't visible the way I have this set up.

Inspired by and compatible with Mauker's series of 6-inch rack accessories and madmax890's models for the series. See the collection here: 6-inch Rack Mounts

Print Settings:

Print with the face down on the plate. Supports aren't needed, but can help the holes print more cleanly. I've printed mine with 25% infill and 3 perimeters, but if I run into any issues I'll add a note here to print with different settings.

Used the blank as a starting point to create a mount specific to the Ubiquiti UXG Lite.
