SCX10I with SCX10II Body - Magnetic Body Mounts / Adjustable Offset
SCX10II body does not fit directly onto an SCX10I (different hole pattern). Here is the solution. Read the description.
2
6
0
149
updated February 23, 2025
Description
PDFThe PostStands from the SCX10I and II have a different hole pattern. SCX10I with 56mm to SCX10II with 72mm. That's why I developed these adapters, with a magnetic function, to put my SCX10II body on my aging grandpa.
- Requires 8 neody magnets (15x3mm with hole for countersunk screw), you can get them on Amazon
- If the holes are offset from front to back, there are two holder versions with different offset sizes.
- If no PostStands are available, I have included the print file for them.
- In order to attach the magnets to the body, I have stored a file for a washer into an M3 nut can be pressed.
Model origin
The author marked this model as their own original creation.
