Snapmaker 2.0 Enclosure - Display holder

3D-Printable Socket for Snapmaker 2.0 Display Enclosure Mounting

This document details the design and printing parameters for a socket designed to mount the Snapmaker 2.0 display on top of the enclosure, utilizing the aluminum profile.

Mechanical Interface:

• Interface with Aluminum Profile: Direct insertion and secured with 2 x M4x10 screws.
• Magnetic Holder Interface: Designed for the angled Snapmaker magnetic holder (not the straight version). Secured with 2 x M4x8 screws.

Printing Specifications:

• Printer: Snapmaker A350 (Dual Extruder, 0.4mm Hot End)
• Material: PETG (AmazonBasics Transparent Blue) - Compatible with other PETG filaments.
• Print Speed: 50 mm/s
• Layer Height: 0.16 mm
• Print Orientation: Front face down (for optimal thread quality)
• Infill Density: ≥ 15%
• Supports: Not Required

This design provides a robust and convenient solution for integrating the Snapmaker 2.0 display with the enclosure.
