K1s - Deluxe Anti Vibration Feet Adapter (Added v.2)

The other Feet Adapters I made work pretty good, but at highest speeds, I did feel the printer swayed more than i wanted, mainly because they are right under he printer, and the printer is tall, and the movement is happening in the top...


So i locked myself in my office again, planned not to come out again, before I had made the Air Jordans of printer feet...

This is the result... These work GREAT... They fit the weight much better too.


They are made so they are less under the printer, and more to the sides, so the printer can not sway like it did.

Dampen my K1 Max perfectly, its very silent now, and barely any vibration.

Gives a lot more clearance under the printer (about 50mm), which allows it to cool better.

They grab the feet firmly, and you can lift the printer, without them falling out.

Protects the corners...

Best feet i had on any printer.

Will Fit K1, K1C and K1 Max.

0.2mm, 4 Walls, 20% Infill.


Need Support. I used "Snug" with a 20% “Threshold Angle” in Orca.

Printet in Elegoo Rapid PETG.

Print Time was about 5 Hours.

Needs longer screw. I used M3 x 15mm.

approx.. 82mm x 60 x 76.

REMEMBER TO CALIBRATE INPUT SHAPER AFTER INSTALLATION...

UPDATE:

Added v.2, with a bottom brace, that will support and help prevent the bottom plate from rattling, as I though it was too noisy, even with very little vibration.

The arms and center piece are flippable, so there is the option to put something soft between. I added soft foam to mine.

Will only fit K1 Max.

Brace Arms: 0.2mm, 3 Walls, 100% Infill.

Brace Center: 0.2mm, 3 Walls, 5% Infill.

Printet in Elegoo Rapid PETG.

Print time was 1 Hour 30 Min.

PURELY FOR PERSONAL USE, AND IS NOT TO BE REMIXED, SHARED, MADE FOR OTHERS OR USED COMMERCIALLY...
Only those ho paid for it, should have access to it, thereby keeping its exclusivity...
Doing so, would be a breach of the copyright license, no different from copying a CD....
Contact me, if you have other suggestions...
