BTT Mini 12864 LCD Housing

BTT LCDs have a longer button and the hole for the knob was too big and let out too much light, so I made the hole…
1
3
0
33
updated February 17, 2025

Description

PDF

BTT LCDs have a longer button and the hole for the knob was too big and let out too much light, so I made the hole smaller and extended the button past the surface to accommodate the longer length.

edit: made a v2 that has a flush face. I also didn't like how the light was shining through the front, so I made the front thicker and the gap around the x button smaller. Haven't tested it to see if the button clears, so may change if it does not.

Category: 3D Printing
