MagicShine Remote Mount
Its a small bracket for the remote of the Magicshine CBL 1600 or EVO 1700.
It uses TPU, 2 PT Screws 3x16 und a zip tie.
1
18
0
70
updated February 17, 2025
Description
PDFIt is a small bracket for the Magicshine remote.
I used 2 small PT screw 3x16 for a small and compact design. The remote is fixed using a small zip tie. I printed the bracket using TPU-CF filament. Regular TPU should work as well.
Printing the bracket as show in the picture avoids support and gives the part a good strength.
The marked holes are closed for a clean and smooth print. Use a 1-1.2mm drill for cleaning the holes.
PT screws are design to work with plastics. I use the screws a lot for parts printed in TPU, TPU-CF and nylon.
Tags
Model origin
The author remixed this model.
Differences of the remix compared to the original
I used 2 small PT screw 3x16 instead of the metric screws.
The remote is fixed using a zip tie instead of the small clips.
