WordClock 16x16 To Fit Ikea SANNAHED 35x35 Frame
Description
PDFhttps://www.ikea.com/gb/en/p/sannahed-frame-black-80459117/#content
https://www.aliexpress.com/item/1005002048512739.html?spm=a2g0o.order_list.order_list_main.77.2a881802ZVR2Nl
Tags
Model origin
The author remixed this model.
Differences of the remix compared to the original
I wanted a wordclock to fit the Ikea Sannahed 35x35 frame, but had to find a mounting solution for the LEDs. I edited the make by @Alexander_38066 in Fusion360 to fit the 256 WS2815 LEDs and created the word layer from scratch.
The final design was too big to fit on my MK4 bed so had to split it into 4 with dovetail joints. I also used the hot soldering iron to help fuse the 4 panels.
Printing the letters was done in black, with a colour change for the defuser, and then another colour change back to black.
The LEDs will need good soldering skills as the 16 strips of LEDs will need to join together to create the matrix.
