Spice Rack made with 10 mm Round Wood

This bracket system is designed for creating versatile shelving solutions using 10mm dowel rods. The design features crush rib holes for the dowel rod connections, which accommodate varying dowel rod tolerances commonly found in commercial wooden rods.

Components:

• Left and right end brackets (one pair per shelf)
• Designed for 10mm dowel rods (not included)

Features:

• Crush rib hole design for dowel rod fitting
• Modular design for shelf building
• Robust construction suitable for spice racks or light storage
• Simple two-piece bracket design

Recommended Print Settings:

• Nozzle: 0.4mm
• Layer Height: 0.2mm
• Wall Count: 3
• Top/Bottom Layers: 4
• Infill: 15%
• Infill Pattern: Cross Hatch
• Material: PLA is fine
• Build Plate Adhesion: Brim recommended for optimal bed adhesion

Assembly: The 10mm dowel rods slide into the crush rib holes. While the design provides a friction fit, adhesive is recommended if the dowel rods are slightly undersize or if a permanent installation is desired. Each shelf unit requires 4 dowel rods.

Notes:

• The bracket system is approximately twice the width of a standard spice rack, making it suitable for various storage applications
• Use wood glue or suitable adhesive if dowel rods are not precisely 10mm
• Print orientation as shown in the model preview for optimal strength

Uses:

• Spice rack organization
• Bathroom storage
• Light decorative shelving
• General household storage solutions

1. Implemented crush rib holes for better dowel rod fit tolerance
2. Added countersunk screw holes for flush mounting
3. Reduced railing height for sleeker appearance
4. Enhanced overall symmetry of the design
5. Added rounded corners and edges for improved aesthetics

Original design by [ https://www.printables.com/@dbw_dad ]
