MK4/MK4S Z Axis Dust Cover

I have gotten a lot of dust and filament scraps down into the deep holes of the z axis motor holder on my MK4S and...
33m
1× print file
0.20 mm
0.40 mm
9.00 g
129
339
14
1437
updated February 9, 2025

Description

PDF

I have gotten a lot of dust and filament scraps down into the deep holes of the z axis motor holder on my MK4S and I wanted some way to stop it from happening. I searched around Printables and found quite a few that I liked, but I thought that I might as well design my own. So I got on FreeCAD made a model and did a draft print to see if it fit. It wasn't exactly what I wanted so I did some modifications to get to this. It fits into the hole and leaves plenty of room for the z screws to rotate.



Print Settings:

For the best quality, print it upside down with supports.

Resolution :0.2SupportsYES
Infill :20%Brim:YES
Material:PETGFilament Color:Orange
