Minisforum BD770i/BD790i/BD795i 92mm cooler mounting plates

The motherboard comes with 120mm cooler mount, which may not be optimal for some builds.

A 92mm cooler is the same width as the radiator.

Hardware needed:

• 6 screws for mounting the brackets to the radiator, they come with the motherboard already
• 4 long screws for mounting the fan to the brackets, I recommend a Thermalright TL-B9 fan because it already comes with them. Or you can widen the holes a bit and use common self-tapping screws for fans, although I haven't tried it myself.

I wouldn't recommend printing it in PLA, but PETG might be just about enough given that the chip loves to heat up to 90°C under some workloads.

ABS/ASA or even nylon are obviously a better choice.

For those who want to make their own mounts:

Distance between the screws in a row is 35mm, distance from one row to another is 125mm.

Onshape link (warning: low effort)
