Home Assistant Yellow Rack Mount Bracket

Major rework of the original RPi Modular 2U Rackmount module mount to hold a Home Assistant Yellow device.

Have also included an embossed Home Assistant logo on the front of the module, along with LED light tunnel holes for Power, Activity and System Health status LED's (pending further work for light tunnels).  I have also included the HA Yellow internal LED support but as mentioned this part is a work in progress.

I printed using PLA with 0.2 layer height, 15% infill, 5 walls, and supports on build plate only.

• The HA Yellow mounts to the modular mount bracket using 4 x M3x8mm screws in place of the original bottom foot screws.
• As per the original designs, the module mount clip/handle attaches to the mount body using 2 x M3x12mm screws (not shown in design files or screenshots).  You will need 2 clips/4 screws for this design.
• I've included the module clip file as well, although this is 100% just a reupload from the source design with no modifications.

The LED light tunnel portion is being researched further as some transparent solid core tubing I am using currently does not let the light travel far enough to appropriately show through the bracket light tunnel holes.

More photos to follow.

As a side note, but still fully compatible, I am actually using the Raspberry Pi 4 19" 2U Rack Mount v2 frame by @commputethis, which is modified from @scaytrase's original model.
