Voron Switchwire Dual Y Motor

NOT TESTED At the moment this is where im keeping all my files so I don't loose them.

499

updated February 5, 2025

Description

what you need:

5x F695 bearing

6x M5 1mm spacers

1x MGN12H Linear Rail - 300mm

5x 20t GT2 pulleys

2x Stailess Steel Rod 5x60mm-Grind Flat

1x GT2 Closed Loop Timing Belt 324mm

1x 2020 Extrusion - 340mm

1m gt2 belt

1x stepper motor

Printed Parts

Y carriages can be cut by www.sendcutsend.com

Distance between rails is 150mm

Each rail is moved 75mm off center.

The author remixed this model.

vorondesign.com

2nd Y rail and motor
