Nerf Removable Bolt for Tri-Strike

A removable model the Nerf Tri-Strike, since you have to saw off the bolts to open the blaster.
6
7
0
134
updated January 26, 2025

Description

PDF

I had to open a Tri-Strike and got pretty annoyed that Hasbro forced those clip designed bolts onto their blasters, so I made a removable one.
You just need two (plastic) screws and the metallic bolt bar from the Tri-Strike. Each bolt is made out of two pieces. It has grooves on the surface for the grip.

The assembly (shown on the picture above): place the "blue" one against the bar, then slide the "red" one against it. Then lock it with turning a screw in. That's it.

Note that this model isn't compatible with the Raptorstrike's bolt, I tried (the shell has a different width).

Feel free to remix it to suit your preferred "bolt action" blaster.
I hope you enjoy!



Settings:

  • Rafts:

No

  • Supports:

No

  • Resolution:

0.2 mm

  • Infill:

15% is good enough

  • Filament brand:

Any

  • Filament color:

Any

  • Filament material:

PLA or PETG
