BMPCC 4K speedbooster support

Simple and small support for Lens adapter (Viltrox EF-M2) and BMPCC4k Tilta cage
16m
1× print file
0.20 mm
0.40 mm
3.00 g
Prusa MK4 & MMU3
1
10
0
98
updated January 26, 2025

Description

PDF

I needed to support my speedbooster Viltrox EF-M2 working together with BMPCC4k (Black Magic Pocket Cinema Camera 4k) in Tilta cage and Sigma 18-35 lens. Unfortunately Smallrig Lens Adapter Support for BMPCC 4K Cage 2769 is not available anywhere and not produced, so I created my own.  That's v1, probably I'll redesign to make it more sturdy, however even now it seems to be working ok (before that lens didn't have any support at all, so that's step forward). Probably should work for Metabones speedboster as well, however I didn't tested that.

Model is split into multiple pieces which make adjustments in Prusa slicer much easier.

Print options:
-No brim
-No supports
-Standard 0.2mm structural profile with:
A) Infill 70%
B) Increased perimeters to 5 (Layers and perimeters > Vertical Shells > Perimeters)

Filament
Prusament Orange PETG

Printer:
Nozzle Brass 0.4mm
Pursa MK4 + MMU3

Screws/Materials:
2x regular round head M4x10
1x 14-20 standard screw?  I've used one from a quick release plate.
