TP-Link EAP265 adapter plate to fit Julsen's EAP613 stand

TP-Link EAP265 adapter plate to fit Julsen's EAP613 stand

Uses the 4 hole mount and adapts to the 3 hole pattern for the EAP265.

Adapter plate recess and pins fit nicely into the 4 hole mounting of the stand.  No glue required but you could easily add a drop or some double sided tape.

4x M4 machine screws required to fit the original TP link mounting plate (low profile heads to enable fitting)

Printed with pins up (obvs.) PLA with 4 wall loops, 3 top and bottom shell layers and 30% grid infill and it is stiff enough for the application given it is supported by the OEM plate.

I will be using this to adapt to other devices.  I just took the original model, imported into Tinkercad and used as a negative to cut out a mounting recess in my model (inset to a 1mm depth).  No scaling and it prints a perfect slight interference fit for the stand, the pins grip the holes with just the natural 3d print layer texture.

Original stand prints efficiently and looks good.  This adapter plate enables use on other devices with different mounting layout pattern.
