raaco 1 slot insert for assortment cabinet

raaco 1 slot insert for assortment cabinet.

One insert has 1 slot and one medium box in the raaco assortment cabinet can store two inserts.

Size

Insert box size
Width: 80 mm.
Depth: 130 mm.
Height: 25.9 mm.

Slot size
Width: 77.6 mm.
Depth: 127.6 mm.
Height: 25 mm.

Printing

Filament: PLA.
Perimeter shells: 2.
Top solid layers: 3.
Bottom solid layers: 3.
First layer height: 0.3 mm.
Layer height: 0.3 mm.

No raft or brim was needed.

There is no infill in this part as the bottom and sides are evenly divisible with the layer height (0.3 mm) and nozzle diameter (0.4 mm).

The bottom chamfer should make the part easier to remove from the build plate.

The part is very basic and can therefore be printed with low quality settings; better tolerances or finish won't do much for the part.
