Pressure Cleaner Wand Surface Mount Storage Clips

1 position and 3 position pressure cleaner wand clips.

I have a long extension and several smaller ones that were going to get damaged leaning them about.  Now the are clipped into brackets on the wall.

In my final version I ended up moving the screw mounts into the center of the clip.  When twisting the wand to get it out of the clamp it would twist the plate with the screws in the plate.

These are sized for #8 screws or for others and M4 screw (hole is 4.6mm).

Designed for 12.8mm (½") OD.  If you need a different diameter let me know.  The clips are 24mm tall.

Printing Instructions

1. Print UPRIGHT for strength
2. I added an extra vertical perimeter ( setting of 3).
3. Normal infill when it needs it 15%
4. I have only tested in PETG which has more native flex.

Note the single position does not have the recess cuts in the plate as the mount screw is there.  You may want to mount it with the plate screw down.  It won't matter.  The plate screw is to prevent spin.
