Prusa XL Pegboard

I wanted a better way to store all my 3D printing tool and keep the readily accessible so I designed a pegboard that mounts to the side of my Prusa XL that has the Sumo Enclosure installed. The pegboard is printed with 0.25 structural profile, 15% infill, and no supports in 4 pieces. The 4 pieces are secured to each other using 4 m4x20 screws and nuts. Then you use 6 m5x16 bolts to secure the pegboard to the Sumo Enclosure's mount points.

The pegboard uses the standard 1" spacing and .25" hole diameter so it is compatible with most hangers. I don't know how well this will work with the filament side mounts as I use dry boxes for my filaments. If you up the infill percentage I can see you being able to mount a 2kg spool to the pegboard.

This pegboard can also be used on the Prusa XL without the Sumo Enclosure using the top and bottom aluminum rails with t-nuts.
